Specifications

1. Lamp Brand: KINGLIGHT

2. Control System: Mooncell

3. Pixel Pitch: 4mm

4. Pixel Configuration: 1R1G1B

5. Internal Size: 1723*1298mm(W*H)*2sets

6. Refresh Rate: ≥1000HZ

7. Brightness: 1800cd/㎡

8. Best Viewing Distance: 4--40m

9. Input Voltage: AC 220V/100V±15%   47～64HZ

10. Max.power consumption（KW）: 3.2

11. Working Temperature/Humidity: -20～60℃，10%～90% RH

12.Flatness: ≤0.5mm between any adjacent pixels;

Splicing gap of unit plate < 1mm

13.All Rate: ＜0.0002

14.Switching Power Load: 5V/40A、5V/60A

15.Drive Way: Constant current drive

16.Effective Communication Distance: The network cable is 100m (no relay), the multi-mode fiber is 500m, and the single-mode fiber is 20km

17.Ingress Protection Rating: IP43

18.Lamp bead life: 100000hrs

19.Warranty: 2 years
